Architape ADL S IP54 Trimless Downlight
The ADL S Trimless IP54 offers seamless architectural integration combined with splash resistant performance for bathrooms, kitchens, and sheltered outdoor environments. Its plaster in trimless design maintains a perfectly clean ceiling appearance while delivering low glare, high quality illumination. This model is ideal for premium interiors that require both architectural simplicity and functional durability
Available Colour Temperatures
Performance at a Glance
High-fidelity metrics for professional specification.
Precision Engineering
Precision Optics
Premium optical assemblies with ultra-low glare (UGR<19) design, providing clean beam definitions and superior visual comfort for high-end applications.
Architectural Integration
Engineered for a seamless, trimless appearance that visually disappears into the ceiling plane while delivering powerful illumination.
Technical Overview
Full Technical Specification
Comprehensive performance data for Architape ADL S IP54 Trimless Downlight.
| Feature | Specification |
|---|---|
| Wattage Range | 9 - 13 W |
| Luminous Flux | 565 - 1133 lm |
| Efficacy | 66 - 94 lm/W |
| IP Rating | IP20 |
| Colour Rendering | CRI 80+, CRI 90+ |
| Optics | R20, R40 |
| Housing | Aluminium Base |
| Warranty | 5 Years Professional Warranty |
Start Your Specification
Access the full range of photometrics, BIM files, and data sheets in our configuration tool.
